IP66 wall-mounted emergency luminaire with automatic self-test and selectable colour temperature (3000K, 4000K, 5000K). Designed for wall installation above emergency exits. Provides 3 hours of emergency lighting in the event of a power failure.

Key product features

Mounting method: Wall surface mounted
Housing colour: Black
Luminous flux in emergency mode (lm): 1000
Colour temperature (K): 3000 – 5000
Function: Escape route lighting
Emergency function monitoring system: Automatic self-test

Product Name

Emergency wall light IP66 | 5/10W 3-CCT | black | auto test

Ean

8714984952034

Outer box qty

4st

Housing material

Aluminium

Lamp type

LED not exchangeable

Housing colour

Black

Material cover

Plastic, transparent

Voltage type

Nominal current

78 - 78mA

Type of control gear

LED operating device voltage-controlled

Battery technology

Lithium-ion

Mounting method

Wall surface mounted

Degree of protection (IP)

IP66

Nominal voltage

220 - 240V

Length

200mm

Width

200mm

Height

90mm

Height/depth

90mm

Colour temperature

3000 - 5000K

Exchangeable control gear

Function

Escape route lighting

With pictogram

Suitable for standby switching

Yes

Suitable for continuous circuit

Yes

Impact strength

IK07

RAL-number housing

9005

Connection type

Plug-in connection

Light distributor

Focal lens

Rated lifetime L70/B50 at 25 °C

50000h

Luminous flux in standby mode

1176lm

Nominal operation time

3 - 3h

Max. system power

18W

Power factor

0.9

Type of wiring

Suitable for loop-through wiring

Number of poles

With heating element for battery

Type of lithium-ion battery

Lithium iron phosphate (LiFePO4)

Rated luminous flux according to IEC 62722-2- 1

605 - 1176lm

Emergency power supply system

Peripheral (individual battery)

Emergency function monitoring system

Automatic self test

Luminous flux in emergency mode

1176lm

Power consumption in emergency mode

10W

Connectable conductor cross section

0.75 - 2.5mm²

Warranty

2 years

Product Name

Emergency wall light IP66 | 5/10W 3-CCT | black | auto test

Suitable for standby switching

Yes

Ean

8714984952034

Suitable for continuous circuit

Yes

Outer box qty

4st

Impact strength

IK07

Housing material

Aluminium

RAL-number housing

9005

Lamp type

LED not exchangeable

Connection type

Plug-in connection

Housing colour

Black

Light distributor

Focal lens

Material cover

Plastic, transparent

Rated lifetime L70/B50 at 25 °C

50000h

Voltage type

Luminous flux in standby mode

1176lm

Nominal current

78 - 78mA

Nominal operation time

3 - 3h

Type of control gear

LED operating device voltage-controlled

Max. system power

18W

Battery technology

Lithium-ion

Power factor

0.9

Mounting method

Wall surface mounted

Type of wiring

Suitable for loop-through wiring

Degree of protection (IP)

IP66

Number of poles

Nominal voltage

220 - 240V

With heating element for battery

Length

200mm

Type of lithium-ion battery

Lithium iron phosphate (LiFePO4)

Width

200mm

Rated luminous flux according to IEC 62722-2- 1

605 - 1176lm

Height

90mm

Emergency power supply system

Peripheral (individual battery)

Height/depth

90mm

Emergency function monitoring system

Automatic self test

Colour temperature

3000 - 5000K

Luminous flux in emergency mode

1176lm

Exchangeable control gear

Power consumption in emergency mode

10W

Function

Escape route lighting

Connectable conductor cross section

0.75 - 2.5mm²

With pictogram

Warranty

2 years

This robust luminaire features a durable aluminium housing (IP66, IK07) and a built-in LiFePO4 battery (6.4 V, 6000 mAh), providing up to 3 hours of emergency operation. It supports both maintained and non-maintained modes and includes a daylight sensor.

The power can be set to 5 W or 10 W, depending on the required light output. In standard mode, the luminaire delivers 550 lumens, while the high-output mode provides up to 1000 lumens. The colour temperature is selectable: 3000K, 4000K or 5000K.

Thanks to its compact, rounded design, this fixture is ideal for use above exit doors, on building facades or in outdoor areas where both function and aesthetics are key.
