Floodlight pro || 300W | 120° | warm white 3000K
146-350300W floodlight with over 130 lm/W efficiency and 120° beam angle. Designed for large-scale outdoor applications that demand high lighting performance. Optional lenses available: 30°, 60° or asymmetric.
Key product features:
- Max. system power (W): 300
- Colour temperature (K): 3000
- Degree of protection (IP), front side: IP66
- Rated luminous flux according to IEC 62722-2-1 (lm): 37.500
Product Name
Floodlight pro || 300W | 120° | warm white 3000K
Ean
8714984937086
Outer box qty
1st
Lamp type
LED not exchangeable
Lamp holder
None
Housing colour
Black
Housing material
Aluminium
Material cover
Glass transparent
Connection type
Schuko plug
Length
370mm
Width
363mm
Height/depth
80mm
Built-in diameter
0 - 0mm
Suitable for built-in mounting
No
Suitable for surface mounting
Yes
Suitable for pedestal/floor mounting
Yes
Suitable for wall mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for light-track mounting
No
Suitable for clamp-mounting
No
With movement sensor
No
With presence detector
No
With light sensor
No
Colour of light
White
Colour consistency (McAdam ellipse)
SDCM3
Colour of light adjustable
No
Colour temperature
3000K
Colour rendering index CRI
80-89
Luminous flux adjustable
No
Light outlet
Direct
Beam angle
> 80° - Extreme wide beam
Beam angle adjustable
No
Voltage type
AC
Nominal voltage
220 - 240V
Nominal current
1330 - 1330mA
Number of poles
3
Light source included
Yes, fixed LED
Light distributor
None
Light distribution
Symmetric
Connectable conductor cross section
0 - 0mm²
Type of control gear
LED operating device current-controlled
Exchangeable control gear
No
With control gear
Yes
Degree of protection (IP), front side
IP66
Surface protection
Powder coating
Impact strength
IK08
Max. system power
300W
Rated luminous flux according to IEC 62722-2- 1
30000 - 30000lm
Luminaire efficacy
100 - 100lm/W
Power factor
0.98
Suitable for lamp power
0 - 0W
Surface brushed
No
Type of wiring
Ending
Emergency power supply system
None
Emergency function monitoring system
None
Adjustability
Rotatable
Unified Glare Ratio (UGR)
33.1
Reflector
None
Warranty
5 years
Product Name
Floodlight pro || 300W | 120° | warm white 3000K
Beam angle
> 80° - Extreme wide beam
Ean
8714984937086
Beam angle adjustable
No
Outer box qty
1st
Voltage type
AC
Lamp type
LED not exchangeable
Nominal voltage
220 - 240V
Lamp holder
None
Nominal current
1330 - 1330mA
Housing colour
Black
Number of poles
3
Housing material
Aluminium
Light source included
Yes, fixed LED
Material cover
Glass transparent
Light distributor
None
Connection type
Schuko plug
Light distribution
Symmetric
Length
370mm
Connectable conductor cross section
0 - 0mm²
Width
363mm
Type of control gear
LED operating device current-controlled
Height/depth
80mm
Exchangeable control gear
No
Built-in diameter
0 - 0mm
With control gear
Yes
Suitable for built-in mounting
No
Degree of protection (IP), front side
IP66
Suitable for surface mounting
Yes
Surface protection
Powder coating
Suitable for pedestal/floor mounting
Yes
Impact strength
IK08
Suitable for wall mounting
Yes
Max. system power
300W
Suitable for ceiling mounting
Yes
Rated luminous flux according to IEC 62722-2- 1
30000 - 30000lm
Suitable for light-track mounting
No
Luminaire efficacy
100 - 100lm/W
Suitable for clamp-mounting
No
Power factor
0.98
With movement sensor
No
Suitable for lamp power
0 - 0W
With presence detector
No
Surface brushed
No
With light sensor
No
Type of wiring
Ending
Colour of light
White
Emergency power supply system
None
Colour consistency (McAdam ellipse)
SDCM3
Emergency function monitoring system
None
Colour of light adjustable
No
Adjustability
Rotatable
Colour temperature
3000K
Unified Glare Ratio (UGR)
33.1
Colour rendering index CRI
80-89
Reflector
None
Luminous flux adjustable
No
Warranty
5 years
Light outlet
Direct
This powerful 300W floodlight is suitable for large-scale lighting applications such as sports facilities, harbours, airports, industrial areas, construction sites and event locations. Also ideal for illuminating large buildings, monuments, terminals, bridges and infrastructural objects.
Supplied with a rubber cable and plug for quick installation, and equipped with a wide 120° light distribution without lens. Optional 60°, 30° or asymmetric lenses available depending on project needs.
Optional bracket available for mounting on Ø65 mm pole. For larger poles (up to Ø150 mm), a heavier bracket is available for one or two floodlights. This makes the fixture flexibly deployable. Either individually or in combination for maximum coverage.
More information
More information about this product can be found in the product specifications. For accessories, available options and related products, see related items. For questions or advice, contact Tronix Lighting via sales@tronixlighting.com or +31 413 330 380.
Datasheet
Datasheet-floodlight-pro-300w-120-warm-white-3000k-146-350.pdf
Energy labels
Manual
146-350_Manual_NL.pdf
146-350_Manual_EN.pdf
Characteristics sheet
146-350-photometric-light-report.pdf
146-350-eulumdat.zip
