LED dimmer double || trailing edge | 2x 2W~100W incl. plate
215-135This double LED dimmer features a dimming function for 2x 2-100W LED lights, including a soft start that allows you to extend the life of connected LED lights. Comes with cover frame and buttons for a complete installation.
Features
- Equipped with dim and on/off function
- Works on the basis of trailing edge
- Soft start to extend the life of connected LED lamps
- Comes with cover and buttons
- Compatible with 55 mm frames of other brands
Product Name
LED dimmer double || trailing edge | 2x 2W~100W incl. plate
Ean
8714984932500
Outer box qty
100st
Colour
Aluminium
Connection type
Screwed terminal
Operating method
Turn/push button
Control method
Trailing edge dimming
Mounting method
Built-in
Material
Metal
Material quality
Aluminium
Device width
71mm
Device height
71mm
Device depth
27mm
Applicable with presence indicator
No
Suitable for degree of protection (IP)
IP20
Applicable with movement sensor
No
Applicable with button
No
Applicable with transmission button
No
Applicable with time switch/timer
No
Nominal voltage
220 - 240V
Control voltage
230 - 240V
Min. depth of built-in installation box
30mm
Min. brightness controllable
No
Max. switching power LED
100W
Light value memory
No
Halogen free
No
RAL-number (similar)
9006
Core cross section
0.75 - 2.5mm²
Warranty
5 years
Product Name
LED dimmer double || trailing edge | 2x 2W~100W incl. plate
Applicable with movement sensor
No
Ean
8714984932500
Applicable with button
No
Outer box qty
100st
Applicable with transmission button
No
Colour
Aluminium
Applicable with time switch/timer
No
Connection type
Screwed terminal
Nominal voltage
220 - 240V
Operating method
Turn/push button
Control voltage
230 - 240V
Control method
Trailing edge dimming
Min. depth of built-in installation box
30mm
Mounting method
Built-in
Min. brightness controllable
No
Material
Metal
Max. switching power LED
100W
Material quality
Aluminium
Light value memory
No
Device width
71mm
Halogen free
No
Device height
71mm
RAL-number (similar)
9006
Device depth
27mm
Core cross section
0.75 - 2.5mm²
Applicable with presence indicator
No
Warranty
5 years
Suitable for degree of protection (IP)
IP20
This double LED dimmer features a dimming function for 2x 2-100W LED lights, including a soft start that allows you to extend the life of connected LED lights. Comes with cover frame and buttons for a complete installation.
Features
Equipped with dim and on/off function
Works on the basis of trailing edge
Soft start to extend the life of connected LED lamps
Comes with cover and buttons
Compatible with 55 mm frames of other brands
