LED dimmer universal | 1-10V
215-133This universal LED dimmer works well with a large selection of LED lighting and can easily be combined with covers from most well-known brands, such as Busch Jaeger, Berker, Gira and Jung. Can also be ordered in combination with universal cover 215-132.
Features
- Built-in on/off and rotary knob dimming control
- Overheating protection
- Smooth dimming compatible with most LED fixtures
- Combination with various LED lamps possible. Want to be sure your combination works? Be sure to ask!
Product Name
LED dimmer universal | 1-10V
Ean
8714984923287
Outer box qty
50st
Colour
Aluminium
Connection type
Screwed terminal
Operating method
Turn/push button
Control method
0/1-10V
Mounting method
Built-in
Material
Metal
Material quality
Aluminium
Device width
83.5mm
Device height
83.5mm
Device depth
44mm
Applicable with presence indicator
No
Suitable for degree of protection (IP)
IP20
Applicable with movement sensor
No
Applicable with button
No
Applicable with transmission button
No
Applicable with time switch/timer
No
Nominal voltage
220 - 240V
Control voltage
1 - 10V
Min. depth of built-in installation box
45mm
Min. brightness controllable
No
Light value memory
Yes
Halogen free
Yes
RAL-number (similar)
9006
Core cross section
0.75 - 2.5mm²
Warranty
5 years
Product Name
LED dimmer universal | 1-10V
Suitable for degree of protection (IP)
IP20
Ean
8714984923287
Applicable with movement sensor
No
Outer box qty
50st
Applicable with button
No
Colour
Aluminium
Applicable with transmission button
No
Connection type
Screwed terminal
Applicable with time switch/timer
No
Operating method
Turn/push button
Nominal voltage
220 - 240V
Control method
0/1-10V
Control voltage
1 - 10V
Mounting method
Built-in
Min. depth of built-in installation box
45mm
Material
Metal
Min. brightness controllable
No
Material quality
Aluminium
Light value memory
Yes
Device width
83.5mm
Halogen free
Yes
Device height
83.5mm
RAL-number (similar)
9006
Device depth
44mm
Core cross section
0.75 - 2.5mm²
Applicable with presence indicator
No
Warranty
5 years
This universal LED dimmer works well with a large selection of LED lighting and can easily be combined with covers from most well-known brands, such as Busch Jaeger, Berker, Gira and Jung. Can also be ordered in combination with universal cover 215-132.
Features
Built-in on/off and rotary knob dimming control
Overheating protection
Smooth dimming compatible with most LED fixtures
Combination with various LED lamps possible. Want to be sure your combination works? Be sure to ask!
Datasheet
Datasheet-led-dimmer-universal-1-10v-215-133.pdf
Manual
215-133_Manual.pdf
Characteristics sheet
215-133_technical_datasheet_extended.pdf
