LED dimmer universal | trailing edge | 1W ~ 150W
215-141Phase-cut LED dimmer with soft-start functionality. Compact, safe and silent – suitable for up to 150W of dimmable LED lighting (230V). Designed for flush mounting in standard EU wall boxes.
Key product features
- Mounting method: Flush-mounted
- Nominal voltage (V): 220 – 240
- Dimming phase cut-on (leading edge): Yes
- Dimming phase cut-off (trailing edge): Yes
- Nominal power capacitive load (VA): 0 – 150
- Connection type: Screw terminal
- Core cross section (mm²): 0.75 – 2.5
- Min. depth of built-in installation box (mm): 24
Product Name
LED dimmer universal | trailing edge | 1W ~ 150W
Ean
8714984951990
Outer box qty
100st
Colour
Black
Connection type
Screwed terminal
Operating method
Turn/push button
Control method
Trailing edge dimming
Mounting method
Built-in
Material
Metal
Material quality
Aluminium
Device width
70mm
Device height
70mm
Device depth
24mm
Applicable with presence indicator
No
Suitable for degree of protection (IP)
IP20
Applicable with movement sensor
No
Applicable with button
No
Applicable with transmission button
No
Applicable with time switch/timer
No
Nominal voltage
220 - 240V
Control voltage
220 - 240V
Min. depth of built-in installation box
25mm
Min. brightness controllable
Yes
Max. switching power LED
150W
Light value memory
Yes
Halogen free
Yes
RAL-number (similar)
9005
Core cross section
0.75 - 2.5mm²
Warranty
5 years
Product Name
LED dimmer universal | trailing edge | 1W ~ 150W
Applicable with movement sensor
No
Ean
8714984951990
Applicable with button
No
Outer box qty
100st
Applicable with transmission button
No
Colour
Black
Applicable with time switch/timer
No
Connection type
Screwed terminal
Nominal voltage
220 - 240V
Operating method
Turn/push button
Control voltage
220 - 240V
Control method
Trailing edge dimming
Min. depth of built-in installation box
25mm
Mounting method
Built-in
Min. brightness controllable
Yes
Material
Metal
Max. switching power LED
150W
Material quality
Aluminium
Light value memory
Yes
Device width
70mm
Halogen free
Yes
Device height
70mm
RAL-number (similar)
9005
Device depth
24mm
Core cross section
0.75 - 2.5mm²
Applicable with presence indicator
No
Warranty
5 years
Suitable for degree of protection (IP)
IP20
This dimmer is designed for flush-mounted applications and supports phase-cut dimming up to 150 watts. It operates on 220–240V AC mains power and uses screw terminals. Minimum installation depth is 24 mm. Suitable for indoor use only.
The dimmer is compatible with most European switchgear brands such as Gira, Jung and Busch-Jaeger. The push-button with soft-start enables silent and comfortable operation. The integrated electronic protection temporarily disables the dimmer in case of overheating or short circuit. Unlike conventional fuses, there is no physical interruption of the circuit – the system automatically resets once the issue is resolved.
Also suitable for two-way switching via a secondary push-button. The minimum dimming level can be manually adjusted via the built-in tuning screw – ideal for preventing flicker at low loads. Matching cover frames are optionally available in white and black.
More information
More information about this product can be found in the product specifications. For accessories, available options and related items, see related products. For questions or advice, contact Tronix Lighting via sales@tronixlighting.com or +31 413 330 380.
