LED strip | COB 840LED/m | 22W/m | IP20 | RGB SPI (WS2811)
127-136RGB SPI COB LED strip with pixel control. Designed for smooth dynamic effects, seamless light output and 50 mm cutting sections.
Key product features
- Lamp power per meter (W): 22
- Width (mm): 12
- Length of particular sections (mm): 50
- Degree of protection (IP): IP20
- Luminous flux per meter (Lm): 814
- Colour of light: RGB
Product Name
LED strip | COB 840LED/m | 22W/m | IP20 | RGB SPI (WS2811)
Ean
8714984948754
Outer box qty
25st
Model
Strip
Lamp type
LED not exchangeable
Lamp voltage
0 - 24V
Number of nodes per meter
840
Lamp power per meter
22W
Beam angle
180°
Voltage type
DC
Type of control gear
LED operating device voltage-controlled
Input voltage tracklights
24V
With protective cover
No
Length of particular segments
50mm
Degree of protection (IP)
IP20
Self-adhesive
Yes
Luminous flux per meter
810lm
Total length
5m
Width
12mm
Height/depth
2mm
Colour of light
RGB
Suitable for dimmer
Yes
Exchangeable control gear
Yes
Connection type
Other
Rated lifetime L70/B50 at 25 °C
54000h
Colour of light adjustable
Continuously variable
Luminous flux per foot
246.89lm
Luminous flux adjustable
Continuously variable
LED type
COB
Max. system power
110W
Beam angle adjustable
No
Luminaire efficacy
40lm/W
Power factor
1
Type of wiring
Loop-through wiring included
Number of poles
3
Connectable conductor cross section
0.5 - 2.5mm²
Colour temperature
RGB SPI
Warranty
3 years
Product Name
LED strip | COB 840LED/m | 22W/m | IP20 | RGB SPI (WS2811)
Height/depth
2mm
Ean
8714984948754
Colour of light
RGB
Outer box qty
25st
Suitable for dimmer
Yes
Model
Strip
Exchangeable control gear
Yes
Lamp type
LED not exchangeable
Connection type
Other
Lamp voltage
0 - 24V
Rated lifetime L70/B50 at 25 °C
54000h
Number of nodes per meter
840
Colour of light adjustable
Continuously variable
Lamp power per meter
22W
Luminous flux per foot
246.89lm
Beam angle
180°
Luminous flux adjustable
Continuously variable
Voltage type
DC
LED type
COB
Type of control gear
LED operating device voltage-controlled
Max. system power
110W
Input voltage tracklights
24V
Beam angle adjustable
No
With protective cover
No
Luminaire efficacy
40lm/W
Length of particular segments
50mm
Power factor
1
Degree of protection (IP)
IP20
Type of wiring
Loop-through wiring included
Self-adhesive
Yes
Number of poles
3
Luminous flux per meter
810lm
Connectable conductor cross section
0.5 - 2.5mm²
Total length
5m
Colour temperature
RGB SPI
Width
12mm
Warranty
3 years
This 24V RGB SPI COB LED strip with integrated WS2811 chip combines seamless light output with pixel-level control. COB technology ensures a homogeneous light effect without visible LEDs – even in shallow or open profiles.
Each 50 mm segment can be individually addressed, allowing smooth gradients, animated lighting effects and programmable scenes.
The built-in WS2811 driver makes the strip compatible with various SPI controllers and digital lighting systems.
Ideal for applications focused on creativity and motion – such as interactive displays, entertainment, events, experience centres and visual communication.
For precision installations, the strip can be cut every 50 mm – enabling flexibility without compromising aesthetics or control.
Effective heat dissipation is essential for optimal performance and a long lifespan. An aluminium LED profile prevents overheating and ensures a clean finish. Combined with GALAXY profiles, this forms a high-quality total solution.
More information
More information about this product can be found in the product specifications. For accessories, available options and related products, see related items. For questions or advice, contact Tronix Lighting via sales@tronixlighting.com or +31 413 330 380.
