Neon Flex | 4x8mm | 24V | 10W/m | 2700K | 30m | solder free
111-002This compact 24V Neon Flex, measuring just 4 x 8 mm, has been developed for interior fit-out and furniture lighting applications. Its short cutting length of 5.56 mm and solder-free connection system make precise customisation quick and easy.
Key product features:
- Lamp voltage (V): 24
- Lamp power per meter (W): 10
- Colour temperature (K): 2700K
- Width (mm): 4
- Length of particular segments (mm): 5.56
- Height/depth (mm): 8
- Degree of protection (IP): IP20
Product Name
Neon Flex | 4x8mm | 24V | 10W/m | 2700K | 30m | solder free
Ean
8714984957695
Outer box qty
1st
Model
Hose
Lamp type
LED not exchangeable
Lamp voltage
24 - 24V
Lamp power per meter
10W
Beam angle
110°
Voltage type
DC
Type of control gear
LED operating device voltage-controlled
With protective cover
No
Length of particular segments
5.56mm
Degree of protection (IP)
IP20
Self-adhesive
No
Luminous flux per meter
185lm
Total length
30m
Width
4mm
Height/depth
8mm
Colour of light
White
Suitable for dimmer
Yes
Colour rendering index CRI
90-100
Exchangeable control gear
Yes
Connection type
Cable
Rated lifetime L70/B50 at 25 °C
50000h
Colour of light adjustable
No
Luminous flux adjustable
Continuously variable
LED type
SMD
Max. system power
300W
Beam angle adjustable
No
Luminaire efficacy
18.5lm/W
Power factor
1
Type of wiring
Ending
Number of poles
2
Type of power supply
Other
Connectable conductor cross section
0.5 - 2.5mm²
Colour temperature
2700K
Warranty
5 years
Ambient temperature
-40 - 55°C
Lowest bending radius
60mm
Connection cable length
0.3m
Product Name
Neon Flex | 4x8mm | 24V | 10W/m | 2700K | 30m | solder free
Colour rendering index CRI
90-100
Ean
8714984957695
Exchangeable control gear
Yes
Outer box qty
1st
Connection type
Cable
Model
Hose
Rated lifetime L70/B50 at 25 °C
50000h
Lamp type
LED not exchangeable
Colour of light adjustable
No
Lamp voltage
24 - 24V
Luminous flux adjustable
Continuously variable
Lamp power per meter
10W
LED type
SMD
Beam angle
110°
Max. system power
300W
Voltage type
DC
Beam angle adjustable
No
Type of control gear
LED operating device voltage-controlled
Luminaire efficacy
18.5lm/W
With protective cover
No
Power factor
1
Length of particular segments
5.56mm
Type of wiring
Ending
Degree of protection (IP)
IP20
Number of poles
2
Self-adhesive
No
Type of power supply
Other
Luminous flux per meter
185lm
Connectable conductor cross section
0.5 - 2.5mm²
Total length
30m
Colour temperature
2700K
Width
4mm
Warranty
5 years
Height/depth
8mm
Ambient temperature
-40 - 55°C
Colour of light
White
Lowest bending radius
60mm
Suitable for dimmer
Yes
Connection cable length
0.3m
With its extremely compact dimensions of 4 x 8 mm, this Neon Flex is particularly suitable for integration into furniture, cabinets, shelving, displays and other interior applications. The narrow 4 mm light-emitting surface makes it possible to create a clean, continuous line of light in areas where installation space is limited.
A key advantage for interior fit-out professionals is the exceptionally short cutting length of just 5.56 mm. This allows the Neon Flex to be cut almost exactly to the required length, resulting in significantly less waste and much greater flexibility for custom applications compared with conventional Neon Flex. Black markings on the side indicate the correct cutting positions.
A special solder-free connection kit is available for installation. Once the Neon Flex has been cut to size, the connector is inserted directly into the Neon Flex and mechanically secured. This eliminates the need for soldering on site. The connection cable comes pre-fitted with an Easy Connect connector.
The Neon Flex bends horizontally and has a minimum bending diameter of 60 mm, allowing it to be installed directly into a routed groove. It offers a colour rendering index of CRI >90, and the maximum connection length when powered from one end is 5 meters.
The Neon Flex is supplied on a 30-meters reel, allowing multiple custom lengths to be produced efficiently from a single reel. Combined with the 5.56 mm cutting length and solder-free connection technology, this makes it a practical solution for series production of custom lighting installations in professional interior fit-out applications.
More information
More information about this product can be found in the product specifications. For accessories, available options and related products, please see the related items. For questions or advice, please contact Tronix Lighting at sales@tronixlighting.com or +31 413 330 380.
