Track spot || 3-phase | white | 20W | 2700K | 40° | dim
169-295The Driver of this dimmable Trackspot is located in the Trackadaptor, so the heat from both the LEDs and the Driver can be dissipated separately. This ensures good heat dissipation and a longer lifespan. For more design options, this white Trackspot comes with a black and a white front ring.
Rails & accessories - 3 phase track
Tronix Lighting offers a wide and diverse range in terms of 3 phase tracks and matching accessories. Each product is available in matching colors for a beautiful, customized result.
Features
- High heat dissipation through separate LEDs and Driver
- Dimmable
- Supplied with white and black front ring
Product Name
Track spot || 3-phase | white | 20W | 2700K | 40° | dim
Ean
8714984941847
Outer box qty
12st
Lamp type
LED not exchangeable
Lamp holder
None
Housing colour
White
Housing material
Plastic
Material cover
Plastic, transparent
Length
186mm
Outer diameter
80mm
Built-in diameter
0 - 0mm
Suitable for built-in mounting
No
Suitable for surface mounting
Yes
Suitable for pedestal/floor mounting
No
Colour
White
Suitable for wall mounting
No
Suitable for ceiling mounting
Yes
Suitable for light-track mounting
Yes
Suitable for clamp-mounting
No
With movement sensor
No
With light sensor
No
Colour of light
White
Colour consistency (McAdam ellipse)
SDCM3
Colour of light adjustable
No
Reflector colour
Silver
Colour temperature
2700K
Colour rendering index CRI
80-89
Luminous flux adjustable
Continuously variable
Light outlet
Direct
Beam angle
21-40° - Medium beam
Beam angle adjustable
No
Voltage type
AC
Nominal voltage
220 - 240V
Nominal current
500 - 500mA
Number of poles
3
Light source included
Yes, fixed LED
Light distributor
Reflector
Light distribution
Symmetric
Connectable conductor cross section
0 - 0mm²
Type of control gear
LED operating device current-controlled
Exchangeable control gear
No
With control gear
Yes
Degree of protection (IP), rear side
IP20
Surface protection
Untreated
Impact strength
IK02
Rated lifetime L70/B50 at 25 °C
50000h
Max. system power
20W
Rated luminous flux according to IEC 62722-2- 1
1400 - 1600lm
Luminaire efficacy
70 - 70lm/W
Power factor
0.9
Suitable for lamp power
0 - 0W
Surface brushed
No
Type of wiring
Ending
Emergency power supply system
None
Emergency function monitoring system
None
Adjustability
Rotating and swivelling
Reflector
High-gloss
Warranty
5 years
Input voltage tracklights
230V
Product Name
Track spot || 3-phase | white | 20W | 2700K | 40° | dim
Beam angle adjustable
No
Ean
8714984941847
Voltage type
AC
Outer box qty
12st
Nominal voltage
220 - 240V
Lamp type
LED not exchangeable
Nominal current
500 - 500mA
Lamp holder
None
Number of poles
3
Housing colour
White
Light source included
Yes, fixed LED
Housing material
Plastic
Light distributor
Reflector
Material cover
Plastic, transparent
Light distribution
Symmetric
Length
186mm
Connectable conductor cross section
0 - 0mm²
Outer diameter
80mm
Type of control gear
LED operating device current-controlled
Built-in diameter
0 - 0mm
Exchangeable control gear
No
Suitable for built-in mounting
No
With control gear
Yes
Suitable for surface mounting
Yes
Degree of protection (IP), rear side
IP20
Suitable for pedestal/floor mounting
No
Surface protection
Untreated
Colour
White
Impact strength
IK02
Suitable for wall mounting
No
Rated lifetime L70/B50 at 25 °C
50000h
Suitable for ceiling mounting
Yes
Max. system power
20W
Suitable for light-track mounting
Yes
Rated luminous flux according to IEC 62722-2- 1
1400 - 1600lm
Suitable for clamp-mounting
No
Luminaire efficacy
70 - 70lm/W
With movement sensor
No
Power factor
0.9
With light sensor
No
Suitable for lamp power
0 - 0W
Colour of light
White
Surface brushed
No
Colour consistency (McAdam ellipse)
SDCM3
Type of wiring
Ending
Colour of light adjustable
No
Emergency power supply system
None
Reflector colour
Silver
Emergency function monitoring system
None
Colour temperature
2700K
Adjustability
Rotating and swivelling
Colour rendering index CRI
80-89
Reflector
High-gloss
Luminous flux adjustable
Continuously variable
Warranty
5 years
Light outlet
Direct
Input voltage tracklights
230V
Beam angle
21-40° - Medium beam
The Driver of this dimmable Trackspot is located in the Trackadaptor, so the heat from both the LEDs and the Driver can be dissipated separately. This ensures good heat dissipation and a longer lifespan. For more design options, this white Trackspot comes with a black and a white front ring.
Rails & accessories - 3 phase track
Tronix Lighting offers a wide and diverse range in terms of 3 phase tracks and matching accessories. Each product is available in matching colors for a beautiful, customized result.
Features
High heat dissipation through separate LEDs and Driver
Dimmable
Supplied with white and black front ring
Datasheet
Datasheet-track-spot-3-phase-white-20w-2700k-40-dim-169-295.pdf
Energy labels
Other attachment
169-295_Luminaire_photometric_test_report.pdf
169-295_Light_Source_Test_Report.pdf
169-295.IES.IES
Characteristics sheet
169-291_295_Manual.pdf
Manual
169-295_Manual_NL.pdf
169-295_Manual_EN.pdf
