LED strip high eff. | 160LED/m 2835 | 5m | IP20 | 4000K
127-141Highly efficient LED strip with 160 LEDs per meter and 160 lm/W. Delivers over 3300 lumens per meter – ideal for high-end luminaires and demanding lighting applications.
Key product features
- Number of nodes per meter: 160
- Lamp power per meter (W): 21
- Colour temperature (K): 4000
- Width (mm): 12
- Length of particular sections (mm): 50
- Degree of protection (IP): IP20
- Luminous flux per meter (Lm): 3368
Product Name
LED strip high eff. | 160LED/m 2835 | 5m | IP20 | 4000K
Ean
8714984952843
Outer box qty
25st
Model
Strip
Lamp type
LED not exchangeable
Lamp voltage
0 - 24V
Number of nodes per meter
160
Lamp power per meter
21W
Beam angle
120°
Voltage type
DC
Type of control gear
LED operating device voltage-controlled
Input voltage tracklights
24V
With protective cover
No
Length of particular segments
50mm
Degree of protection (IP)
IP20
Self-adhesive
Yes
Luminous flux per meter
3016lm
Total length
5m
Width
12mm
Height/depth
1.2mm
Colour of light
White
Suitable for dimmer
Yes
Colour rendering index CRI
80-89
Exchangeable control gear
Yes
Connection type
Other
Rated lifetime L70/B50 at 25 °C
54000h
Colour of light adjustable
No
Luminous flux per foot
919.28lm
Luminous flux adjustable
Continuously variable
LED type
SMD
Max. system power
105W
Beam angle adjustable
No
Luminaire efficacy
151lm/W
Power factor
1
Type of wiring
Loop-through wiring included
Number of poles
2
Connectable conductor cross section
0.5 - 2.5mm²
Colour temperature
4000K
Warranty
3 years
Product Name
LED strip high eff. | 160LED/m 2835 | 5m | IP20 | 4000K
Colour of light
White
Ean
8714984952843
Suitable for dimmer
Yes
Outer box qty
25st
Colour rendering index CRI
80-89
Model
Strip
Exchangeable control gear
Yes
Lamp type
LED not exchangeable
Connection type
Other
Lamp voltage
0 - 24V
Rated lifetime L70/B50 at 25 °C
54000h
Number of nodes per meter
160
Colour of light adjustable
No
Lamp power per meter
21W
Luminous flux per foot
919.28lm
Beam angle
120°
Luminous flux adjustable
Continuously variable
Voltage type
DC
LED type
SMD
Type of control gear
LED operating device voltage-controlled
Max. system power
105W
Input voltage tracklights
24V
Beam angle adjustable
No
With protective cover
No
Luminaire efficacy
151lm/W
Length of particular segments
50mm
Power factor
1
Degree of protection (IP)
IP20
Type of wiring
Loop-through wiring included
Self-adhesive
Yes
Number of poles
2
Luminous flux per meter
3016lm
Connectable conductor cross section
0.5 - 2.5mm²
Total length
5m
Colour temperature
4000K
Width
12mm
Warranty
3 years
Height/depth
1.2mm
This highly efficient 24V LED strip with 160 premium 2835 SMD LEDs per metre delivers over 3300 lumens of output. With a luminous efficacy of 160 lm/W, it is designed for applications that demand maximum light output and energy efficiency.
Its dense LED layout ensures uniform illumination, suitable for both direct and indirect applications. Thanks to the 50 mm cutting section, precise fitting is easy to achieve.
This strip is ideally suited for integration into luminaires such as linear profiles or custom lighting modules. It also excels in commercial and architectural applications, workplace lighting, light lines or lightboxes where wide coverage is needed with fewer metres.
Effective heat dissipation is essential for optimal performance and a long lifespan. An aluminium LED profile prevents overheating and ensures a clean finish. Combined with GALAXY profiles, this forms a high-quality total solution.
More information
More information about this product can be found in the product specifications. For accessories, available options and related products, see related items. For questions or advice, contact Tronix Lighting via sales@tronixlighting.com or +31 413 330 380.
Datasheet
Datasheet-led-strip-high-eff-160ledm-2835-5m-ip20-4000k-127-141.pdf
Energy labels
Characteristics sheet
127-141-photometric-light-report.pdf
127-140.ldt
