LED strip narrow | 5mm | 240LED/m 2216 | 5m | IP20 | 2700K
127-146Slim 24V LED strip, 5 mm wide, with 240 efficient 2216 LEDs per meter. Ideal for refined applications thanks to its short cutting section and uniform light output.
Key product features
- Number of nodes per meter: 240
- Lamp power per meter (W): 10
- Colour temperature (K): 2700
- Width (mm): 5
- Length of particular sections (mm): 25
- Degree of protection (IP): IP20
- Luminous flux per meter (Lm): 862
Product Name
LED strip narrow | 5mm | 240LED/m 2216 | 5m | IP20 | 2700K
Ean
8714984927599
Outer box qty
25st
Model
Strip
Lamp type
LED not exchangeable
Lamp voltage
0 - 24V
Number of nodes per meter
240
Lamp power per meter
10W
Beam angle
120°
Voltage type
DC
Type of control gear
LED operating device voltage-controlled
Input voltage tracklights
24V
With protective cover
No
Length of particular segments
25mm
Degree of protection (IP)
IP20
Self-adhesive
Yes
Luminous flux per meter
740lm
Total length
5m
Width
5mm
Height/depth
1.2mm
Colour of light
White
Suitable for dimmer
Yes
Colour rendering index CRI
90-100
Exchangeable control gear
Yes
Connection type
Other
Rated lifetime L70/B50 at 25 °C
54000h
Colour of light adjustable
No
Luminous flux per foot
225.55lm
Luminous flux adjustable
Continuously variable
LED type
SMD
Max. system power
50W
Beam angle adjustable
No
Luminaire efficacy
75lm/W
Power factor
1
Type of wiring
Loop-through wiring included
Number of poles
2
Connectable conductor cross section
0.5 - 2.5mm²
Colour temperature
2700K
Warranty
3 years
Product Name
LED strip narrow | 5mm | 240LED/m 2216 | 5m | IP20 | 2700K
Colour of light
White
Ean
8714984927599
Suitable for dimmer
Yes
Outer box qty
25st
Colour rendering index CRI
90-100
Model
Strip
Exchangeable control gear
Yes
Lamp type
LED not exchangeable
Connection type
Other
Lamp voltage
0 - 24V
Rated lifetime L70/B50 at 25 °C
54000h
Number of nodes per meter
240
Colour of light adjustable
No
Lamp power per meter
10W
Luminous flux per foot
225.55lm
Beam angle
120°
Luminous flux adjustable
Continuously variable
Voltage type
DC
LED type
SMD
Type of control gear
LED operating device voltage-controlled
Max. system power
50W
Input voltage tracklights
24V
Beam angle adjustable
No
With protective cover
No
Luminaire efficacy
75lm/W
Length of particular segments
25mm
Power factor
1
Degree of protection (IP)
IP20
Type of wiring
Loop-through wiring included
Self-adhesive
Yes
Number of poles
2
Luminous flux per meter
740lm
Connectable conductor cross section
0.5 - 2.5mm²
Total length
5m
Colour temperature
2700K
Width
5mm
Warranty
3 years
Height/depth
1.2mm
This slim 24V LED strip with 240 pcs 2216 SMD LEDs per metre and 10 watts per metre is ideal for narrow aluminium profiles and custom projects. The efficient 2216 SMD LEDs ensure a calm and uniform light output. Thanks to a short 25 mm cutting section, the strip allows precise customisation.
Available in 2700K, 3000K and 4000K, suitable for various lighting applications. Use an aluminium LED profile for optimal heat dissipation and a clean finish. Combined with GALAXY profiles, this creates a high-quality total solution.
More information
More information about this product can be found in the product specifications. For accessories, available options and related products, see related items. For questions or advice, contact Tronix Lighting via sales@tronixlighting.com or +31 413 330 380.
Datasheet
Datasheet-led-strip-narrow-5mm-240ledm-2216-5m-ip20-2700k-127-146.pdf
Energy labels
Characteristics sheet
127-146-photometric-light-report.pdf
127-146.ldt
