Adj. downl || white | Ø180mm | 45° | 4000K | 6~15W | EU plug
136-336This rotate and swivel downlight offers optimum light output combined with adjustable Max. system power. The modern, white fixture is perfect for precise and flexible lighting adjustments in both commercial and residential spaces.
Key product features:
- Adjustability: Rotating and swivelling
- Max. system power (W): 6 – 15
- Colour temperature (K): 4000
- Housing colour: White
- Outer diameter (mm): 180
- Built-in diameter (mm): 165 - 175
- Connection type: Plug
Product Name
Adj. downl || white | Ø180mm | 45° | 4000K | 6~15W | EU plug
Ean
8714984948303
Outer box qty
12st
Lamp type
LED not exchangeable
Lamp holder
None
Housing colour
White
Housing material
Aluminium
Material cover
Glass transparent
Connection type
EU plug
Height/depth
128.5mm
Outer diameter
180mm
Built-in diameter
165 - 175mm
Suitable for built-in mounting
Yes
Suitable for surface mounting
No
Suitable for pedestal/floor mounting
No
Suitable for wall mounting
No
Suitable for ceiling mounting
Yes
Suitable for light-track mounting
No
Suitable for clamp-mounting
Yes
With movement sensor
No
With presence detector
No
With light sensor
No
Colour of light
White
Colour consistency (McAdam ellipse)
SDCM6
Colour of light adjustable
No
Reflector colour
Silver
Colour temperature
4000K
Colour rendering index CRI
80-89
Luminous flux adjustable
No
Light outlet
Direct
Beam angle
41-80° - Wide beam
Beam angle adjustable
No
Voltage type
AC
Nominal voltage
220 - 240V
Nominal current
62 - 62mA
Number of poles
2
Light distributor
Reflector
Light distribution
Symmetric
Connectable conductor cross section
0.75 - 2.5mm²
Type of control gear
LED operating device current-controlled
Exchangeable control gear
No
With control gear
Yes
Degree of protection (IP), front side
IP30
Degree of protection (IP), rear side
IP20
Surface protection
Lacquered
Impact strength
IK02
Rated lifetime L70/B50 at 25 °C
50000h
Max. system power
15W
Rated luminous flux according to IEC 62722-2- 1
660 - 1650lm
Luminaire efficacy
110 - 110lm/W
Power factor
0.96
Suitable for lamp power
0 - 0W
Dimming method
Non-dimmable
Surface brushed
No
Type of wiring
Ending
Emergency power supply system
None
Emergency function monitoring system
None
Adjustability
Rotating and swivelling
Unified Glare Ratio (UGR)
24.4
Reflector
High-gloss
Warranty
5 years
Product Name
Adj. downl || white | Ø180mm | 45° | 4000K | 6~15W | EU plug
Beam angle adjustable
No
Ean
8714984948303
Voltage type
AC
Outer box qty
12st
Nominal voltage
220 - 240V
Lamp type
LED not exchangeable
Nominal current
62 - 62mA
Lamp holder
None
Number of poles
2
Housing colour
White
Light distributor
Reflector
Housing material
Aluminium
Light distribution
Symmetric
Material cover
Glass transparent
Connectable conductor cross section
0.75 - 2.5mm²
Connection type
EU plug
Type of control gear
LED operating device current-controlled
Height/depth
128.5mm
Exchangeable control gear
No
Outer diameter
180mm
With control gear
Yes
Built-in diameter
165 - 175mm
Degree of protection (IP), front side
IP30
Suitable for built-in mounting
Yes
Degree of protection (IP), rear side
IP20
Suitable for surface mounting
No
Surface protection
Lacquered
Suitable for pedestal/floor mounting
No
Impact strength
IK02
Suitable for wall mounting
No
Rated lifetime L70/B50 at 25 °C
50000h
Suitable for ceiling mounting
Yes
Max. system power
15W
Suitable for light-track mounting
No
Rated luminous flux according to IEC 62722-2- 1
660 - 1650lm
Suitable for clamp-mounting
Yes
Luminaire efficacy
110 - 110lm/W
With movement sensor
No
Power factor
0.96
With presence detector
No
Suitable for lamp power
0 - 0W
With light sensor
No
Dimming method
Non-dimmable
Colour of light
White
Surface brushed
No
Colour consistency (McAdam ellipse)
SDCM6
Type of wiring
Ending
Colour of light adjustable
No
Emergency power supply system
None
Reflector colour
Silver
Emergency function monitoring system
None
Colour temperature
4000K
Adjustability
Rotating and swivelling
Colour rendering index CRI
80-89
Unified Glare Ratio (UGR)
24.4
Luminous flux adjustable
No
Reflector
High-gloss
Light outlet
Direct
Warranty
5 years
Beam angle
41-80° - Wide beam
With a tilt angle of up to 35° and a rotation range of 270°, this downlight offers maximum flexibility. Ideal for accent or general lighting, it is perfectly suited to evolving interior needs. Suitable for tasks such as highlighting artwork or providing focused task lighting.
This series includes three sizes: 96 mm, 145 mm, and 180 mm. Available in color temperatures of 3000K or 4000K, enabling a choice between warm or neutral white light. Installation is hassle-free with connection options such as a Euro or GST18i3 plug. A perfect solution for environments where adaptability and ambiance are essential.
Additional Information
More details about this product can be found in the specifications. For accessories, available options, and related products, see the related items section. For inquiries or advice, contact Tronix Lighting at sales@tronixlighting.com or +31 413 330 380.
Datasheet
Datasheet-adj-downl-white-o180mm-45-4000k-615w-eu-plug-136-336.pdf
Energy labels
Manual
136-336_Manual_NL.pdf
136-336_Manual_EN.pdf
Characteristics sheet
136-336-photometric-light-report.pdf
136-336-photometric-light-report-detailed.zip
136-336-eulumdat.zip
